41SH35

Martin 41SH35 Type B Single Strand Solid Bushed Roller Chain Sprocket, 0.5 to 1.688 in Dia Bore, 5.855 in OD, #41 Chain, 35 Teeth, 1/2 in Pitch, Steel

  • Item#: 41SH35
  • Mfr#: 41SH35
  • UPC: 697950009438
    • Interchangeable with other manufacturer's QD® bushings
    • Precise machining and processes ensure consistent finish and high quality
    • Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
    • Bores are concentric to pitch line, minimizing run out
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

QD (quick detachable) is a sprocket where a tapered bushing is bolted into the taper bore that is machined in the sprocket. When installed this bushing is compressed onto the shaft providing a tight grip.

Martin Roller Chain Sprocket, Type B Single Strand Solid Bushed, 0.5 to 1.688 in Bore, 5.855 in OD, #41 Chain, 35 Teeth, 1/2 in Pitch, 5.5779 in Pitch Diameter, 3 in Diameter Hub, 13/16 in Length Through Bore, QD® SH Bushing, Steel

SPECIFICATIONS

Bushing Type      :      QD® SH
Bore Diameter      :      0.5 to 1.688 in
Outside Diameter      :      5.855 in
Chain Size      :      #41
Number of Teeth      :      35
Pitch      :      1/2 in
Material      :      Steel
Type      :      Type B Single Strand Solid Bushed
Pitch Diameter      :      5.5779 in
Hub Diameter      :      3 in
Length Through Bore      :      13/16 in

DOCUMENTS

  • pdf
    Specification Sheet     https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Martin_815A13B_Specification_Sheet.pdf
  • video VIDEO LINK https://www.youtube.com/watch?v=fSomOMNB_-Q
