Martin 40BB18NM 5/8
Martin

Martin 40BB18NM 5/8

loading
Martin
Email Print

40BB18NM 5/8

Martin 40BB18NM 5/8 BB-NM Ball Bearing Non-Metallic Type A Idler Roller Chain Sprocket, 5/8 in Dia Bore, 3.136 in OD, 40 Chain, 18 Teeth, 1/2 in Pitch, Plastic

  • Item#: 40BB18NM 5/8
  • Mfr#: 40BB18NM 5/8
  • UPC: 697950353135
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Martin idlers are smooth-running and available in oil-impregnated, sintered bronze, extra-duty bearing press-fitted in sprocket and a hardened steel journal case for maximum resistance to wear. Steel sprockets used in Martin idlers are accurately machined (not stamped) the same as sprockets normally supplied for power transmission use. Martin can also alter existing sprockets and install bearings to make custom idlers.

Martin Idler Roller Chain Sprocket, Ball Bearing Non-Metallic Type A, Series: BB-NM, 5/8 in Bore Dia, 3.136 in Outside Dia, 40 Chain, 18 Teeth, 1/2 in Pitch, 2.879 in, 2-1/4 in Hub Dia, 0.72 in Length Through Bore, Plastic

SPECIFICATIONS

Pitch      :      1/2 in
Series      :      BB-NM
Bore Diameter      :      5/8 in
Outside Diameter      :      3.136 in
Chain Size      :      40
Number of Teeth      :      18
Material      :      Plastic
Pitch Diameter      :      2.879 in
Length Through Bore      :      0.72 in
Hub Diameter      :      2-1/4 in
Type      :      Ball Bearing Non-Metallic Type A

DOCUMENTS

  • pdf
    Catalog     https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Martin_35BB20H_5_8_Catalog.pdf
