30L075 SDS
Martin 30L075 SDS Solid Type EF-1 Stock Timing Pulley, 1/2 to 2 in QD® Bushed Bore, 3.551 in OD, 30 Grooves, 3.581 in Dia Pitch, 1 in W Face
- CP#:
- Item#: 30L075 SDS
- Mfr#: 30L075 SDS
- UPC: 697950151946
- Exhibit many of the best features of chain drives and belt drives
- Non-slip toothed drive with no metal to metal contact
- No lubrication needed
- Precise machining and processes ensure consistent finish and high quality
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Martin timing pulleys are manufactured to extremely close specifications and are stocked in minimum plain bore, taper bushed, QD bushed styles depending on size and pitch. Synchronous sprockets are non-slip toothed drives that require no lubrication. These sprockets have a wide speed range, are very efficient and make less noise than chain drives. Teeth on the belts are molded to conform with and engage the teeth on a mating sprocket.
Martin Stock Timing Pulley, Solid Type EF-1, QD® Bushed Bore, 1/2 to 2 in Bore Dia, 3.551 in Outside Dia, 3.581 in, 30 Grooves, 3/8 in Pitch, 1 in Face Width, 3.805 in Flange Dia, SDS Bushing, 1-3/8 in Overall Length, For Use With: 3/4 in W Type L Belt, Steel
SPECIFICATIONS
| Overall Length | : | 1-3/8 in |
| Pitch | : | 3/8 in |
| Material | : | Steel |
| Bushing Type | : | SDS |
| Bore Diameter | : | 1/2 to 2 in |
| Bore Type | : | QD® Bushed |
| Outside Diameter | : | 3.551 in |
| Number of Grooves | : | 30 |
| Pitch Diameter | : | 3.581 in |
| Face Width | : | 1 in |
| Type | : | Solid Type EF-1 |
| Flange Diameter | : | 3.805 in |
| Suitable For Use With | : | 3/4 in W Type L Belt |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Martin_10L050_Catalog.pdf
