200U32
Martin 200U32 Type 6 Single Strand Welded Bushed Roller Chain Sprocket, 2-3/8 to 5-1/2 in Dia Bore, 26.883 in OD, #200 Chain, 32 Teeth, 2-1/2 in Pitch, Steel
- CP#:
- Item#: 200U32
- Mfr#: 200U32
- UPC: 697950164915
- Interchangeable with other manufacturer's split-taper bushings
- Precise machining and processes ensure consistent finish and high quality
- Chain rows are parallel and precisely spaced to increase longevity of sprocket and chain
- Bores are concentric to pitch line, minimizing run out
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Martin split taper sprocket is another style of bushed sprocket. The split taper bushing, when installed, offers a wide range of bore sizes.
Martin Roller Chain Sprocket, Type 6 Single Strand Welded Bushed, 2-3/8 to 5-1/2 in Bore, 26.883 in OD, #200 Chain, 32 Teeth, 2-1/2 in Pitch, 25.5057 in Pitch Diameter, 8-1/2 in Diameter Hub, 1-1/4 in Keyway, 3-3/4 in Length Through Bore, MST® U0 Bushing, Steel
SPECIFICATIONS
| Bushing Type | : | MST® U0 |
| Bore Diameter | : | 2-3/8 to 5-1/2 in |
| Outside Diameter | : | 26.883 in |
| Chain Size | : | #200 |
| Number of Teeth | : | 32 |
| Pitch | : | 2-1/2 in |
| Material | : | Steel |
| Keyway Size | : | 1-1/4 in |
| Hub Diameter | : | 8-1/2 in |
| Type | : | Type 6 Single Strand Welded Bushed |
| Pitch Diameter | : | 25.5057 in |
| Length Through Bore | : | 3-3/4 in |
