100A80
Martin 100A80 Type A Single Strand Solid Reboreable Roller Chain Sprocket, 1.5 to 30.535 in Dia Bore, 32.565 in OD, #100 Chain, 80 Teeth, 1-1/4 in Pitch, Steel
- CP#:
- Item#: 100A80
- Mfr#: 100A80
- UPC: 697950023816
- Precise machining and processes ensure consistent finish and high quality
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
A Plates are flat sprockets with no hub extension on either side. They can be altered for your application with bolt holes, custom bores, hardened teeth or special hubs welded to them.
Martin Roller Chain Sprocket, Type A Single Strand Solid Reboreable, 1.5 to 30.535 in Bore, 32.565 in OD, #100 Chain, 80 Teeth, 1-1/4 in Pitch, 31.8392 in Pitch Diameter, 0.692 in Length Through Bore, Steel
SPECIFICATIONS
| Bore Diameter | : | 1.5 to 30.535 in |
| Outside Diameter | : | 32.565 in |
| Chain Size | : | #100 |
| Number of Teeth | : | 80 |
| Pitch | : | 1-1/4 in |
| Material | : | Steel |
| Type | : | Type A Single Strand Solid Reboreable |
| Pitch Diameter | : | 31.8392 in |
| Length Through Bore | : | 0.692 in |
