Lovejoy® 68514410621
Lovejoy®

Lovejoy® 68514410621

loading
Lovejoy®
Email Print

68514410621

Lovejoy® 68514410621 Type L Solid Spider, L/AL075 Coupling, 1-3/4 in OD, 11000 rpm Max, Buna-N

  • Item#: L/AL075 SPIDER SOX (NBR)
  • Mfr#: 68514410621
  • UPC: 685144106216
    • Nitrile Butadiene (Buna N) Rubber is a flexible elastomer material that is oil-resistant, resembles natural rubber in resilience and elasticity and operates effectively in temperature range of -40 to 212 deg F (-40 to 100 deg C)
    • Good resistance to oil
    • Standard elastomer (also applies to SXB cushions)
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Lovejoy® Spider, Type L Solid, L/AL075 Coupling, 1-3/4 in OD, 10.2 N-m Torque, 11000 rpm Maximum, For Use With: Type L Jaw Coupling, -40 to 212 deg F, 80A Durometer, Buna-N, Black

SPECIFICATIONS

Type      :      Type L Solid
Outside Diameter      :      1-3/4 in
Material      :      Buna-N
Torque Rating      :      10.2 N-m
Durometer      :      80A
Suitable For Use With      :      Type L Jaw Coupling
Temperature Rating      :      -40 to 212 deg F
Finish      :      Black
Coupling Size      :      L/AL075
Maximum Speed      :      11000 rpm

DOCUMENTS

  • pdf
    Specification Sheet     https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Lovejoy_68514410621_Specification_Sheet.pdf
  • pdf
    Catalog     https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Lovejoy_68514411133_Catalog.pdf
  • pdf
    Manual     https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Lovejoy_68514411333_Manual.pdf
  • video VIDEO LINK https://www.youtube.com/watch?v=I0D0nrwzzm0&feature=youtu.be
