Link-Belt® ER35 200 Standard-Duty Unmounted Ball Bearing Unit With Lube Groove and Locating Ring, 2-3/16 in Dia Bore, 3.937 in OD, 2-3/16 in W, 9800 lb Dynamic/6570 lb Static Load

  • Item#: ER35MB
  • Mfr#: ER35
  • UPC: 662864003476
  • Compact 1-piece housing provides excellent mounting support
  • Alignable precision deep groove ball bearing manufactured of quality alloy bearing steel provides high capacity and long life
  • Adapter series with cylindrical outside diameter
  • Spherical outside diameter of outer ring
  • Non-relubricatable bearing
  • Setscrew locking device
  • 211 size code
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

200 series standard duty ball bearing units provide a versatility of application arrangements for carrying shafts with radial or combination radial and thrust loads. They are designed for general purpose industrial machinery, conveyors, chain and belt drives, fans and blowers, power transmission and many other applications.

Link-Belt® Ball Bearing Unit, Standard-Duty Unmounted, Series: 200, 2-3/16 in Bore, 3.937 in OD, 2-3/16 in Width, 9800 lb Dynamic/6570 lb Static Load, Cast Iron Bearing, 4360 rpm Maximum, 225 deg F, Uncoated

SPECIFICATIONS

Series      :      200
Bearing Material      :      Cast Iron
Finish      :      Uncoated
Load Capacity      :      9800 lb Dynamic/6570 lb Static
Maximum Speed      :      4360 rpm
Outside Diameter      :      3.937 in
Inside Diameter      :      2-3/16 in
Mounted      :      Yes
Width      :      2-3/16 in

DOCUMENTS

  • pdf
    Catalog     https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Link-Belt_11KB204N_Catalog.pdf
  • pdf
    Manual     https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Link-Belt_TAS2160406_Manual.pdf
