NAXK50Z
Koyo NAXK50Z Metric Series Caged Round Bore Combined Needle Roller Bearing With Thrust Washer Retaining Dust Cap, 50 mm Dia Bore, 70 mm OD, 1 Row, 35 mm W, 30.2 kN Dynamic/68.5 kN Static Radial/28.8 kN Dynamic/75.4 kN Static Thrust Load
- CP#:
- Item#: NAXK50Z
- Mfr#: NAXK50Z
- UPC: 605790213519
- 6470 lbf dynamic/17000 lbf static load
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Koyo Combined Needle Roller Bearing, Caged Round Bore, Series: NAXK Metric Series, 50 mm Bore, 71.5 mm OD, 1 Rows, 35 mm Width, 30.2 kN Dynamic/68.5 kN Static Radial/28.8 kN Dynamic/75.4 kN Static Thrust Load, Steel Bearing, Steel Cage, 4300 rpm Oil Maximum, -25 to 225 deg F
SPECIFICATIONS
| Series | : | NAXK Metric Series |
| Bearing Material | : | Steel |
| Load Capacity | : | 30.2 kN Dynamic/68.5 kN Static Radial/28.8 kN Dynamic/75.4 kN Static Thrust |
| Maximum Speed | : | 4300 rpm Oil |
| Outside Diameter | : | 71.5 mm |
| Number of Rows | : | 1 |
| Width | : | 35 mm |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/127/Koyo_NA2262RS_Catalog.pdf
