ZKLF1255-2RS-XL
INA ZKLF1255-2RS-XL ZKLF..-2RS Axial Angular Contact Ball Bearing With Predrilled Mounting Flange, 12 mm Dia Bore, 55 mm OD, 2 Rows, 25 mm W, 60 deg, 18600 N Dynamic/24700 N Static/1460 N Fatigue Load
- CP#:
- Item#: ZKLF1255-2RS
- Mfr#: ZKLF1255-2RS-XL
- UPC: 03537314100
- Double direction
- Lip seals on both sides
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
INA Axial Angular Contact Ball Bearing, Series: ZKLF..-2RS, 12 mm Bore Dia, 55 mm Outside Dia, 2 Rows, 25 mm W, 60 deg Contact, Sealed Closure, 18600 N Dynamic/24700 N Static/1460 N Fatigue, Plastic Cage, 9200 rpm Limiting for Grease/3800 rpm Thermally Safe Operating Maximum, -30 to 120 deg C
SPECIFICATIONS
| Series | : | ZKLF..-2RS |
| Contact Angle | : | 60 deg |
| Load Capacity | : | 18600 N Dynamic/24700 N Static/1460 N Fatigue |
| Maximum Speed | : | 9200 rpm Limiting for Grease/3800 rpm Thermally Safe Operating |
| Outside Diameter | : | 55 mm |
| Number of Rows | : | 2 |
| Width | : | 25 mm |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/INA_DKLFA2590_2RS_Catalog.pdf -
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/INA_ZKLF1255_2RS_L_Specification_Sheet.pdf
