SL05026-E

INA SL05026-E Full Complement Fixed Cylindrical Roller Bearing, 130 mm Dia Bore, 200 mm OD, 2 Rows, 65 mm W, 810 kN Load

  • Item#: SL05026-E
  • Mfr#: SL05026-E
  • UPC: 03537312566
  • Locating bearing function
  • Spherical OD for static self-aligning
  • Increased capacity design
  • Without cage
  • 435 kN dynamic/810 kN static
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Full complement cylindrical roller bearings comprise solid outer and inner rings and rib-guided cylindrical rollers. Since these bearings feature the largest possible number of rolling elements, they have extremely high radial load carrying capacity, high rigidity and are suitable for particularly compact designs. Due to their kinematic conditions, however, they cannot achieve the high speeds that are possible when using cylindrical roller bearings with cage. Full complement cylindrical roller bearings are available as non-locating, semi-locating and locating bearings as well as in single and double-row designs.

INA Cylindrical Roller Bearing, Full Complement Fixed, Series: SL05, 130 mm Bore, 200 mm OD, 2 Rows, 65 mm Width, 810 kN Load, 800 rpm Maximum, -30 to 120 deg C

SPECIFICATIONS

Series      :      SL05
Load Capacity      :      810 kN
Maximum Speed      :      800 rpm
Outside Diameter      :      200 mm
Number of Rows      :      2
Width      :      65 mm
