NKXR40-XL
INA NKXR40-XL Single Direction Needle Roller/Axial Cylindrical Roller Bearing, 40 mm Dia Bore, 52 mm OD, 32 mm W, 47000 N Load
- CP#:
- Item#: NKXR40
- Mfr#: NKXR40-XL
- UPC: 03537339400
- The bearings can support high radial loads and moderate axial loads by means of a single bearing position
- Suitable for applications with a very small radial design envelope, where the raceway on the shaft is designed as a rolling bearing raceway
- Permit relatively high speeds, if the rolling element set in the axial bearing component is not full complement but guided by a cage
- High running accuracy
- Permit locating bearing arrangements with only a very small radial design envelope
- Result in axially rigid bearing arrangements
- Easy to mount as they are not self-retaining in many cases
- Permit technically straightforward, economical and cost-effective designs
- For oil lubrication
- Without inner ring
- Without end cap
- X-life design
- 29500 N dynamic/47000 N static radial, 56000 N dynamic/148000 N static axial
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
These bearings comprise a radial needle roller bearing and an axial cylindrical roller bearing of series 811 with a plastic cage. They do not have an inner ring and require a shaft raceway that is hardened and ground. If the shaft cannot be used as a rolling bearing raceway, inner rings IR can be used instead. The suitable inner rings are given in the product tables and must be ordered in addition to the bearing . For lubrication, the outer ring of the radial bearing component has a lubrication groove and lubrication holes. Type NKXR is not self-retaining, i.e. the radial needle roller bearing, axial cylindrical roller bearing and shaft locating washer can be fitted independently of each other.
INA Needle Roller/Axial Cylindrical Roller Bearing, Single Direction, Series: NKXR, 40 mm Bore, 52 mm OD, 32 mm Width, Open Closure, 47000 N Load, Sheet Steel Cage, 6000 rpm Maximum, -30 to 120 deg C
SPECIFICATIONS
| Series | : | NKXR |
| Load Capacity | : | 47000 N |
| Maximum Speed | : | 6000 rpm |
| Outside Diameter | : | 52 mm |
| Width | : | 32 mm |
DOCUMENTS
-
Warranty Information https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/INA_NIPA1_Warranty.pdf
