NKI65/25-XL
INA NKI65/25-XL NKI Series Precision Needle Roller Bearing, 65 mm Dia Bore, 90 mm OD, 25 mm W, 60000 N Dynamic/100000 N Static/17500 N Fatigue Load
- CP#:
- Item#: NKI65/25
- Mfr#: NKI65/25-XL
- UPC: 03537308771
- Cage guided rollers
- Ground raceways with ribs
- Through hardened machined and ground raceways with cage and roller complements
- Retainer guides needles providing full length roller contact for maximum capacity, low friction and long life
- Design series exist to match ISO, DIN, popular metric and inch dimension series
- Location hole and groove in outer ring
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
INA Precision Needle Roller Bearing, Series: NKI Series, 65 mm Bore Dia, 90 mm Outside Dia, 25 mm W, Open Closure, 60000 N Dynamic/100000 N Static/17500 N Fatigue, Steel Cage, 6300 rpm Maximum, -20 to 120 deg C
SPECIFICATIONS
| Series | : | NKI Series |
| Load Capacity | : | 60000 N Dynamic/100000 N Static/17500 N Fatigue |
| Maximum Speed | : | 6300 rpm |
| Outside Diameter | : | 90 mm |
| Width | : | 25 mm |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/INA_DKLFA2590_2RS_Catalog.pdf -
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/INA_NKI65_25_L_Specification_Sheet.pdf
