NK12/16-XL
INA NK12/16-XL NK Series Precision Needle Roller Bearing, 12 mm Dia Bore, 19 mm OD, 1 Row, 16 mm W, 10100 N Dynamic/11000 N Static/1920 N Fatigue Load
- CP#:
- Item#: NK12/16
- Mfr#: NK12/16-XL
- UPC: 03537308528
- Without inner ring
- Ground raceways with ribs
- Cage guided rollers
- Through hardened machined and ground raceways with cage and roller complements
- Retainer guides needles providing full length roller contact for maximum capacity, low friction and long life
- Design series exist to match ISO, DIN, popular metric and inch dimension series
- Location hole and groove in outer ring
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
INA Precision Needle Roller Bearing, Series: NK Series, 12 mm Bore Dia, 19 mm Outside Dia, 1 Row, 16 mm W, Open Closure, 10100 N Dynamic/11000 N Static/1920 N Fatigue, Steel Cage, 26500 rpm Maximum
SPECIFICATIONS
| Series | : | NK Series |
| Load Capacity | : | 10100 N Dynamic/11000 N Static/1920 N Fatigue |
| Maximum Speed | : | 26500 rpm |
| Outside Diameter | : | 19 mm |
| Number of Rows | : | 1 |
| Width | : | 16 mm |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/INA_DKLFA2590_2RS_Catalog.pdf -
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/INA_NK12_16_L_Specification_Sheet.pdf
