KBZ10
INA KBZ10 KBZ Series Linear Ball Bushing Bearing, Closed Closure, 5/8 in Dia Shaft, 1-1/8 in OD, 1-1/2 in L
- CP#:
- Item#: KBZ10
- Mfr#: KBZ10
- UPC: 03537315326
- Corrosion-resistant design possible
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Linear ball bearings of series KBZ consist of a hardened and ground solid outer ring and a retainer. The outer ring is machined from high-carbon bearing steel. The retainer is manufactured from a high strength engineered resin.
INA Linear Ball Bushing Bearing, Series: KBZ Series, 5/8 in Shaft Dia, 1-1/8 in Outside Dia, 1-1/8 in Height, 1-1/2 in Length, 1-1/8 in W, Closed Closure, 174 lbf Dynamic/265 lbf Static, Chrome Steel Bearing, Linear Lube Lubrication, -4 to 176 deg F
SPECIFICATIONS
| Bearing Material | : | Chrome Steel |
| Height | : | 1-1/8 in |
| Load Capacity | : | 174 lbf Dynamic/265 lbf Static |
| Lubrication Type | : | Linear Lube |
| Series | : | KBZ Series |
| Temperature Rating | : | -4 to 176 deg F |
| Width | : | 1-1/8 in |
| Closure Type | : | Closed |
| Shaft Diameter | : | 5/8 in |
| Outside Diameter | : | 1-1/8 in |
| Length | : | 1-1/2 in |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/INA_DKLFA2590_2RS_Catalog.pdf -
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/INA_KBZ10_Specification_Sheet.pdf
