GE40-AW-A

INA GE40-AW-A Axial Spherical Plain Bearing, 40 mm Dia Bore, 105 mm OD, 1 Row, 32 mm W, 1870000 N Load

  • Item#: GE40-AW
  • Mfr#: GE40-AW-A
  • UPC: 03537326099
  • Sliding contact surface hard chromium/ELGOGLIDE®
  • Shaft locating washer curved surface with hard chromium coating
  • Maintenance-free
  • 1120000 N dynamic/1870000 N static
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Spherical roller bearings are designed for systems in which high loads must be supported and shaft flexing and misalignments compensated. They deliver extremely high performance and are designed to carry extreme loads. The decades of experience our engineers have gathered combined with innovative ideas improve our spherical roller bearings even further. As a matter of fact, our quest for perfection in development and production ensures optimum kinematics and low wear, which increases the service life even more. And that comes at a low maintenance outlay and minimum maintenance costs. Axial spherical roller bearings are single-row roller bearings with an angular adjustment facility. They comprise solid shaft and housing locating washers and asymmetrical barrel rollers with cages. The cage holds the roller and cage assembly and the shaft locating washer together. The bearings can be dismantled. As a result, the bearing components can be fitted separately.

INA Spherical Plain Bearing, Axial, Series: GE-AW, 40 mm Bore, 105 mm OD, 1 Rows, 32 mm Width, Open Closure, 1870000 N Load, -50 to 150 deg C

SPECIFICATIONS

Series      :      GE-AW
Load Capacity      :      1870000 N
Number of Rows      :      1
Outside Diameter      :      105 mm
Width      :      32 mm
