AKL.GT17

INA AKL.GT17 GT Series Single Direction Separable Axial Deep Groove Ball Bearing, 38.18 mm Dia Bore, 65.89 mm OD, 15.88 mm W, 19300 N Load

  • Item#: GT17
  • Mfr#: AKL.GT17
  • UPC: 03537305985
  • Standardized, ready-to-fit units with high axial load carrying capacity
  • Suitable exclusively for the support of predominantly axial
  • Permit higher speeds than roller or needle roller and cage assemblies
  • 19300 N dynamic/44500 N static
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Axial deep groove ball bearings comprise shaft locating washers, housing locating washers and ball and cage assemblies. The bearings are not self-retaining, the ball and cage assembly and bearing washers can therefore be fitted separately. In addition to the series with flat washers, series are also available with spherical housing locating washers for the compensation of static angular misalignment. These designs are normally used in conjunction with seating washers. Axial deep groove ball bearings are available in single and double direction designs. Both designs can support high axial forces but cannot be subjected to radial loads.

INA Axial Deep Groove Ball Bearing, Single Direction Separable, Series: GT Series, 38.18 mm Bore, 65.89 mm OD, 15.88 mm Width, Open Closure, 19300 N Load, Steel Bearing, 3800 rpm Maximum

SPECIFICATIONS

Series      :      GT Series
Bearing Material      :      Steel
Load Capacity      :      19300 N
Maximum Speed      :      3800 rpm
Outside Diameter      :      65.89 mm
Width      :      15.88 mm

DOCUMENTS
