- Formsprag Clutch® RSBW30
RSBW30
Formsprag Clutch® RSBW30 Sprag Clutch, 30 mm Dia Bore, 106 mm OD, 447 ft-lb Torque, 400 rpm Max
- CP#:
- Item#: RSBW30
- Mfr#: RSBW30
- UPC: 786582330970
- Special purpose designs
- Grease lubrication
- Without keyseat
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Model RSBW is a specialized backstop based on a DC sprag type dual cage retainer assembly. It is self contained utilizing a combined outer race and torque arm, which incorporates plain bearings suitable for low rotational speeds and seals using shield protected O-rings. Primarily used as a backstop, this model provides high torque capacity with a minimum space.
Formsprag Clutch® Sprag Clutch, Series: RSBW, 30 mm Bore, 106 mm OD, 48 mm Overall Length, 447 ft-lb Torque, 400 rpm Maximum, Vertical (Zero-U) Mounting
SPECIFICATIONS
| Mounting Type | : | Vertical (Zero-U) |
| Overall Length | : | 48 mm |
| Series | : | RSBW |
| Bore Diameter | : | 30 mm |
| Outside Diameter | : | 106 mm |
| Torque Rating | : | 447 ft-lb |
| Maximum Speed | : | 400 rpm |
DOCUMENTS
-
Manual https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/287/Formsprag_Clutch_HSB7503000_Manual.pdf -
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/382/Formsprag_Clutch_HSB7503000_Catalog.pdf -
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/69/Formsprag_Clutch_RSBW25_Specification_Sheet.pdf
