6206-2Z-L038-C3
FAG 6206-2Z-L038-C3 62..-2Z Deep Groove Ball Bearing, 30 mm Dia Bore, 62 mm OD, 1 Rows, 16 mm W, 20700 N Dynamic/11300 N Static/760 N Fatigue Load
- CP#:
- Item#: 6206-2Z-L038-C3
- Mfr#: 6206-2Z-L038-C3
- UPC: 4012802649598
- Gap seal on both sides
- C3 radial internal clearance
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
FAG Deep Groove Ball Bearing, Series: 62..-2Z, 30 mm Bore, 62 mm OD, 1 Rows, 16 mm Width, Double Shield Closure, 20700 N Dynamic/11300 N Static/760 N Fatigue Load, Steel Bearing, Metal Seal, Steel Cage, 13800 rpm Maximum, -30 to 120 deg C, Uncoated
SPECIFICATIONS
| Series | : | 62..-2Z |
| Bearing Material | : | Steel |
| Finish | : | Uncoated |
| Load Capacity | : | 20700 N Dynamic/11300 N Static/760 N Fatigue |
| Maximum Speed | : | 13800 rpm |
| Outside Diameter | : | 62 mm |
| Number of Rows | : | 1 |
| Seal Material | : | Metal |
| Width | : | 16 mm |
