VCJT1 7/16
Timken® Fafnir® VCJT1 7/16 VCJT Normal Duty Standard Flange Mount Ball Bearing Unit, 1-7/16 in Dia Bore, 5-1/8 in L Bolt Center-to-Center, 2-Bolt Flange Mount, 6-1/8 in OAL/Dia
- CP#:
- Item#: VCJT1 7/16
- Mfr#: VCJT1 7/16
- UPC: 087796059443
- This series has the same design and features as the VCJ type, but has two bolt holes instead of four
- This series is assembled with GRA-RRB bearings with positive-contact, land-riding seals and self-locking collars
- The units are factory pre-lubricated
- A grease fitting is provided for relubrication
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Timken® ball bearing housed units feature a wide-inner-ring ball bearing for additional shaft support. Designed for mounting on straight shafts with a slip fit, these housed units are available in an extensive array of types and sizes to accommodate many industrial applications.
Timken® Fafnir®, VCJT1 7/16, Flange Mount Ball Bearing Unit, Normal Duty Standard, Series: VCJT, 1-7/16 in Bore, 5-1/8 in Bolt Center-to-Center Length, 2-Bolt Flange Mounting, 6-1/8 in Overall Length/Diameter, 1.989 in Overall Depth, 1.989 in Overall Height, Eccentric Locking Device, Steel Bearing, 6400 lb Dynamic/3440 lb Static Load, 3930 rpm Maximum, -30 to 275 deg F, Uncoated
SPECIFICATIONS
| Bolt Center-to-Center Length | : | 5-1/8 in |
| Series | : | VCJT |
| Bearing Material | : | Steel |
| Finish | : | Uncoated |
| Flange Mounting Type | : | 2-Bolt |
| Locking Device | : | Eccentric |
| Load Capacity | : | 6400 lb Dynamic/3440 lb Static |
| Maximum Speed | : | 3930 rpm |
| Overall Depth | : | 1.989 in |
| Overall Height | : | 1.989 in |
| Inside Diameter | : | 1-7/16 in |
| Overall Length/Diameter | : | 6-1/8 in |
| Measurement System | : | Imperial |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Timken_RCJO2_7_16_Catalog.pdf -
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Timken_VCJT1_7_16_Specification_Sheet.pdf
