TCJT1 7/16

Timken® Fafnir® TCJT1 7/16 TCJT Industrial Normal Duty Flange Mount Ball Bearing Unit, 1-7/16 in Dia Bore, 5-1/8 in L Bolt Center-to-Center, 2-Bolt Flange Mount, 6-1/8 in OAL/Dia

  • Item#: TCJT1 7/16
  • Mfr#: TCJT1 7/16
  • UPC: 087796059399
    • The cartridges are the same basic design as RCJ, TCJ, and LCJ types, except they have two bolt holes instead of four
    • This series is primarily designed for applications where the mounting area is restricted
    • The TCJT is equipped with G-KPPB (tri-ply seal) wide-inner-ring ball bearings
    • The units are factory pre-lubricated
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Timken® ball bearing housed units feature a wide-inner-ring ball bearing for additional shaft support. Designed for mounting on straight shafts with a slip fit, these housed units are available in an extensive array of types and sizes to accommodate many industrial applications.

Timken® Fafnir®, TCJT1 7/16, Flange Mount Ball Bearing Unit, Industrial Normal Duty, Series: TCJT, 1-7/16 in Bore, 5-1/8 in Bolt Center-to-Center Length, 2-Bolt Flange Mounting, 6-1/8 in Overall Length/Diameter, 2.106 in Overall Depth, 2.106 in Overall Height, Eccentric Locking Device, Steel Bearing, 6400 lb Dynamic/3440 lb Static Load, 500 rpm Maximum, -30 to 275 deg F, Uncoated

SPECIFICATIONS

Bolt Center-to-Center Length      :      5-1/8 in
Series      :      TCJT
Bearing Material      :      Steel
Finish      :      Uncoated
Flange Mounting Type      :      2-Bolt
Locking Device      :      Eccentric
Load Capacity      :      6400 lb Dynamic/3440 lb Static
Maximum Speed      :      500 rpm
Overall Depth      :      2.106 in
Overall Height      :      2.106 in
Inside Diameter      :      1-7/16 in
Overall Length/Diameter      :      6-1/8 in
Measurement System      :      Imperial
