KAS1 7/16 PS
Timken® Fafnir® KAS1 7/16 PS KAS Series Standard Duty Pillow Block Ball Bearing Housed Unit, 1.003 in Dia Bore, 5.12 in L Bolt Center-to-Center, 1-5/16 in Base to Bore Centerline, 6.56 in OAL x 3.69 in OAH
- CP#:
- Item#: KAS1 7/16 PS
- Mfr#: KAS1 7/16 PS
- UPC: 087796213463
- The 300 series stainless steel insert provides high resistance to corrosion
- Loads are lighter and corrosion protection is the primary concern
- Specifically designed for light loads and low speeds and has stainless steel setscrews
- The durable, corrosion proof polymer housing has stainless steel crush bushings in the mounting holes and a stainless steel grease fitting with nylon cap
- Polymer resists a broad range of acids and alkalis
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Designed to maximize performance, Timken® Fafnir® ball bearing housed units combine the bearing, housing, seal and locking system into one device for easy installation and operation. Timken® Fafnir® housed units feature specialized product lines to solve specific application concerns. Our problem solver series helps prevent downtime by using superior technology to keep equipment running efficiently and improve your bottom line.
Timken® Fafnir®, KAS1 7/16 PS, Pillow Block Ball Bearing Housed Unit, Standard Duty, Series: KAS Series, 1.003 in Bore, 5.12 in Bolt Center-to-Center Length, 1-5/16 in Base to Bore Centerline, 6.56 in Overall Length, 1.961 in Overall Width, 3.69 in Overall Height, High Base Mounting, Round Bore, Set Screw Locking Device, 240 lb Static Load, 300 rpm Maximum, Polymer
SPECIFICATIONS
| Base to Bore Centerline | : | 1-5/16 in |
| Series | : | KAS Series |
| Bolt Center-to-Center Length | : | 5.12 in |
| Mounting Type | : | High Base |
| Locking Device | : | Set Screw |
| Overall Length | : | 6.56 in |
| Load Capacity | : | 240 lb Static |
| Material | : | Polymer |
| Maximum Speed | : | 300 rpm |
| Overall Width | : | 1.961 in |
| Inside Diameter | : | 1.003 in |
| Overall Height | : | 3.69 in |
| Measurement System | : | Imperial |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Fafnir_010_10650_Catalog.pdf -
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Fafnir_KAS1_1_4_PS_Specification_Sheet.pdf
