FLCT1
Timken® Fafnir® FLCT1 FLCT Normal Duty Standard Flange Mount Ball Bearing Unit, 1.001 in Dia Bore, 3 in L Bolt Center-to-Center, 2-Bolt Flange Mount, 3-3/4 in OAL/Dia
- CP#:
- Item#: FLCT1
- Mfr#: FLCT1
- UPC: 087796057142
- These versatile power-transmission units are designed to provide sturdy shaft support in minimum space at minimum cost
- The space-saving, two bolt unit mounts flush against the frame
- The bolt-hole spacing and size is the same as the pressed-steel flangette unit
- The series is equipped with RA-RRB extended inner-ring ball bearings with positive-contact, land-riding seals
- The series is permanently pre-lubricated
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Timken® ball bearing housed units feature a wide-inner-ring ball bearing for additional shaft support. Designed for mounting on straight shafts with a slip fit, these housed units are available in an extensive array of types and sizes to accommodate many industrial applications.
Timken® Fafnir®, FLCT1, Flange Mount Ball Bearing Unit, Normal Duty Standard, Series: FLCT, 1.001 in Bore, 3 in Bolt Center-to-Center Length, 2-Bolt Flange Mounting, 3-3/4 in Overall Length/Diameter, 1-23/64 in Overall Depth, 1.329 in Overall Height, Eccentric Locking Device, Steel Bearing, 3150 lb Dynamic/1760 lb Static Load, 5440 rpm Maximum, -30 to 275 deg F, Uncoated
SPECIFICATIONS
| Bolt Center-to-Center Length | : | 3 in |
| Series | : | FLCT |
| Bearing Material | : | Steel |
| Finish | : | Uncoated |
| Flange Mounting Type | : | 2-Bolt |
| Locking Device | : | Eccentric |
| Load Capacity | : | 3150 lb Dynamic/1760 lb Static |
| Maximum Speed | : | 5440 rpm |
| Overall Depth | : | 1-23/64 in |
| Overall Height | : | 1.329 in |
| Inside Diameter | : | 1.001 in |
| Overall Length/Diameter | : | 3-3/4 in |
| Measurement System | : | Imperial |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Fafnir_GVFD1_1_2_Catalog.pdf
