VEP6F6
Dixon® VEP6F6 DQC VEP Hydraulic Plug, 3/4 in x 3/4-14 Nominal, Female NPTF, Steel, Domestic
- CP#:
- Item#: VEP6F6
- Mfr#: VEP6F6
- DORS retention system optimizes flow and impulse pressure performance
- Thread-to-connect design and dual valve system allows for connecting under pressure
- Threaded design eliminates premature wear or brinelling commonly found with locking ball designs when subjected to high impulse pressures
- Stainless steel retaining rings and springs maximize corrosion resistance and extend service life
- Steel componentry is plated using ROHS compliant zinc nickel for superior corrosion resistance
- Valve stems have molded polyurethane seals
- Ancillary nipple seals are nitrile
- TPC-ET anti-extrusion ring protects main coupling valve seal from dynamic impulse pressure damage
- 3/4 in body
- 22.7 gpm flow
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Dixon® Hydraulic Plug, Series: DQC VEP, 3/4 in x 3/4-14 Nominal, Female NPTF, 38 mm Hex, 4.12 in Length, 5500 psi, Steel, 1.98 in OD, Domestic
SPECIFICATIONS
| Dimensions | : | 1.98 in OD |
| Hex Size | : | 38 mm |
| Length | : | 4.12 in |
| Pressure Rating | : | 5500 psi |
| Series | : | DQC VEP |
| Nominal Size | : | 3/4 in x 3/4-14 |
| End Style | : | Female NPTF |
| Material | : | Steel |
| Domestic/Import | : | Domestic |
