RBU29
Dixon® RBU29 Boss™ 4-Bolt Clamp, 2-32/64 to 2-50/64 in Nominal, Stainless Steel Band, Domestic
- CP#:
- Item#: RBU29
- Mfr#: RBU29
- UPC: 089109802791
- 4-bolt type clamp with 2 gripping fingers and 2 clamp sections
- Bolts in Boss™ clamps are designed to bend as they are tightened, this allows the clamp to conform to the hose outside diameter
- Always tighten bolts to their specified torque value
- Periodic re-tightening of bolts is required due to "cold flow" phenomenon present in all rubber hoses
- Boss™ clamps are for single use only, once removed they are to be discarded
- Recommended for steam service up to 450 deg F
- The bolts used in the boss interlocking clamps are not standard bolts
- They vary from standard bolts in their length, diameter, overall thread length and material hardness
- These bolts can be retorqued, but it is not recommended that the bolts or clamps be reused, as they are designed for a single bend only
- When installing stainless steel bolts and nuts, the use of anti-seize or anti-galling lubricant is advised, a light coat is required on the bolts to prevent thread galling and artificial torque reading
- Worn-out hose couplings can be dangerous
- They should be checked regularly and replace when necessary
- Each coupling user should review applications and add safety devices where indicated
- Recommended torque rating in ft. lbs
- Note: pressurized steam is an extremely dangerous commodity
- Only hose, fittings, clamps and accessory items that have been approved for steam service should ever be used! never use an unapproved item for steam service
- Always follow the manufacturer's product recommendations for pressurized steam handling
- Warning: this product contains a chemical known to the State of California to cause birth defects or other reproductive harm
- Do not use in connection with drinking water
- Wash hands after handling
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Dixon® 4-Bolt Clamp, Series: Boss™, 2-32/64 to 2-50/64 in Nominal, 4-13/32 in Length, 3-7/8 in Width, 60 ft-lb, Stainless Steel Band, Domestic
SPECIFICATIONS
| Length | : | 4-13/32 in |
| Series | : | Boss™ |
| Torque Rating | : | 60 ft-lb |
| Width | : | 3-7/8 in |
| Nominal Size | : | 2-32/64 to 2-50/64 in Hose |
| Band Material | : | Stainless Steel |
| Domestic/Import | : | Domestic |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_187_Catalog.pdf -
VIDEO LINK
http://www.youtube.com/watch?v=wYrt27WXkqY&feature=share&list=PL10BD55ADAF82DEDA&index=9
