GLBRC160
Dixon® GLBRC160 Gauge, 0 to 160 psi, 1/4 in Connection, 2-1/2 in Dial, +/- 2-1-2 %, Glycerin Liquid Filled
- CP#:
- Item#: GLBRC160
- Mfr#: GLBRC160
- UPC: 089109707737
- Brass movement with highly polished bearing surfaces
- Solid cast brass case with polished ABS cover ring
- Do not use in connection with drinking water
- Wash hands after handling
- Acrylic window with membrane assembly
- Copper alloy bourdon tube
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Dixon® Gauge, 0 to 160 psi, 1/4 in, 2-1/2 in Dial Diameter, +/- 2-1-2 % Accuracy, Liquid Filled: Glycerin, -4 to 140 deg F, Center Back Mount, Cast Brass Case
SPECIFICATIONS
| Material | : | Cast Brass Case |
| Mounting Type | : | Center Back |
| Temperature Rating | : | -4 to 140 deg F |
| Pressure Range | : | 0 to 160 psi |
| Connection Size | : | 1/4 in |
| Dial Diameter | : | 2-1/2 in |
| Accuracy | : | +/- 2-1-2 % |
| Liquid Filled | : | Glycerin |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_Valve_Coupling_GBR100_Catalog.pdf
