GL130
Dixon® GL130 Standard Dry Gauge, 0 to 160 psi, 1/4 in Connection, 2 in Dial, +/- 3-2-3 %
- CP#:
- Item#: GL130
- Mfr#: GL130
- UPC: 089109707706
- PowerFlex™ movement with polyester segment, designed to resist the effects of shock, vibration and pulsation
- Black aluminum pointer
- C-shaped bronze safety bourdon tube
- Do not use in connection with drinking water
- Wash hands after handling
- Polycarbonate window
- Corrosion-resistant, ABS plastic case
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Dixon® Gauge, Standard Dry, 0 to 160 psi, 1/4 in, 2 in Dial Diameter, +/- 3-2-3 % Accuracy, -40 to 150 deg F, Lower Mount, ABS Case
SPECIFICATIONS
| Material | : | ABS Case |
| Mounting Type | : | Lower |
| Temperature Rating | : | -40 to 150 deg F |
| Type | : | Standard Dry |
| Pressure Range | : | 0 to 160 psi |
| Connection Size | : | 1/4 in |
| Dial Diameter | : | 2 in |
| Accuracy | : | +/- 3-2-3 % |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_Valve_Coupling_2731R_Catalog.pdf
