Dixon®
GBR100
Dixon® GBR100 Standard Dual Scale Dry Gauge, 0 to 100 psi/kPa, 1/4 in Connection, 2-1/2 in Dial, +/- 3-2-3 %
- Item#: GBR100
- Mfr#: GBR100
- Polished brass ring
- Do not use in connection with drinking water
- Wash hands after handling
- Copper alloy bourdon tube
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Dixon® Gauge, Standard Dual Scale Dry, 0 to 100 psi/kPa, 1/4 in, 2-1/2 in Dial Diameter, +/- 3-2-3 % Accuracy, -40 to 140 deg F, Lower Mount, Brass Case, Polished
SPECIFICATIONS
| Finish | : | Polished |
| Material | : | Brass Case |
| Mounting Type | : | Lower |
| Temperature Rating | : | -40 to 140 deg F |
| Type | : | Standard Dual Scale Dry |
| Pressure Range | : | 0 to 100 psi/kPa |
| Connection Size | : | 1/4 in |
| Dial Diameter | : | 2-1/2 in |
| Accuracy | : | +/- 3-2-3 % |
