Dixon® 4030-B-AL
Dixon®

Dixon® 4030-B-AL

loading

4030-B-AL

Dixon® 4030-B-AL Type B Cam and Groove Reducing Coupler, 3 x 4 in Nominal, Female Coupler x MNPT End Style, Aluminum, Domestic

  • Item#: 4030-B-AL
  • Mfr#: 4030-B-AL
    • 11-5/32 in open x 6-9/16 in closed across cam arm
    • Precision machined to rigid tolerances
    • Stainless pins will not rust or bind, providing great strength and safety
    • Recess holds gasket firmly in place - ensures proper placement
    • Buna-N gasket
    • Durable stainless steel cam arm pins
    • Produced to interchange with all product produced to commercial item description A-A-59326D
    • In reducing couplings, the cam and groove end is the first size in the part number
    • Under no circumstances should cam and groove couplings be used for compressed air or steam service!
    • Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70 deg F with a standard seal installed
    • Warning: this product contains a chemical known to the state of California to cause birth defects or other reproductive harm
    • Do not use in connection with drinking water
    • Wash hands after handling
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Dixon® Cam and Groove Reducing Coupler, Type B, Reducing Coupling Fitting/Connector, 3 x 4 in Nominal, Female Coupler x MNPT End Style, 5-7/16 in Length, 100 psi Pressure, Aluminum, Domestic

⚠ WARNING: This product can expose you to chemicals including one or more chemicals which are known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

SPECIFICATIONS

Length      :      5-7/16 in
Pressure Rating      :      100 psi
Fitting/Connector Type      :      Reducing Coupling
Type      :      Type B
Nominal Size      :      3 x 4 in
End Style      :      Female Coupler x MNPT
Material      :      Aluminum
Domestic/Import      :      Domestic

DOCUMENTS

  • pdf
    Catalog
    https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_Valve_Coupling_4030-B-AL_Catalog.pdf
  • pdf VIDEO LINK http://youtu.be/Vgth_9M5IRM?list=PL10BD55ADAF82DEDA
