2HF2-B
Dixon® 2HF2-B H Series Hydraulic Interchange Coupler, 1/4 in x 1/4-18 Nominal, Quick-Connect x Female NPTF, Brass Body/Buna-N Seal, Domestic
- CP#:
- Item#: B16-263
- Mfr#: 2HF2-B
- Stainless steel balls, retaining rings and springs maximize corrosion resistance and extend service life
- Steel coupler sleeves are hardened to resist deformation and maximize service life
- Valve seals are crimped in place to maintain integrity during excessive flow conditions and pressurized connection
- Has a redundant o-ring sealing system
- 15000 psi burst pressure
- 1.12 in OD max
- 7/8 in hex
- Poppet Shut Off Valve
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Dixon® Hydraulic Interchange Coupler, Series: H Series, 1/4 in x 1/4-18 Nominal, Quick-Connect x Female NPTF, 2.26 in Length, 3000 psi, -40 to 250 deg F, Brass Body/Buna-N Seal, Domestic
SPECIFICATIONS
| Length | : | 2.26 in |
| Pressure Rating | : | 3000 psi |
| Series | : | H Series |
| Temperature Rating | : | -40 to 250 deg F |
| Nominal Size | : | 1/4 in x 1/4-18 |
| End Style | : | Quick-Connect x Female NPTF |
| Material | : | Brass Body/Buna-N Seal |
| Domestic/Import | : | Domestic |
