- Dixon® 250-D-AL
250-D-AL
Dixon® 250-D-AL Type D Cam and Groove Coupler, 2-1/2 in Nominal, Female Coupler x FNPT End Style, Aluminum, Domestic
- CP#:
- Item#: 250-D-AL
- Mfr#: 250-D-AL
- Precision machined to rigid tolerances
- Stainless pins will not rust or bind, providing great strength and safety
- Recess holds gasket firmly in place - ensures proper placement
- Long shank design allows proper banding, thus eliminating the major cause of hose damage
- Buna-N gasket
- Durable stainless steel cam arm pins
- Produced to interchange with all product produced to commercial item description A-A-59326D
- Parts are manufactured in Canada, replacement handle: part no CARP12BZ
- Under no circumstances should cam and groove couplings be used for compressed air or steam service!
- Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70 deg F with a standard seal installed
- Warning: this product contains a chemical known to the state of California to cause birth defects or other reproductive harm
- Do not use in connection with drinking water
- Wash hands after handling
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Dixon® Cam and Groove Coupler, Type D, Coupling Fitting/Connector, 2-1/2 in Nominal, Female Coupler x FNPT End Style, 3.011 in Length, 150 psi Pressure, Aluminum, 3-3/8 in H Dimensions, Domestic
SPECIFICATIONS
| Dimensions | : | 3-3/8 in H |
| Length | : | 3.011 in |
| Pressure Rating | : | 150 psi |
| Fitting/Connector Type | : | Coupling |
| Type | : | Type D |
| Nominal Size | : | 2-1/2 in |
| End Style | : | Female Coupler x FNPT |
| Material | : | Aluminum |
| Domestic/Import | : | Domestic |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_Valve_Coupling_250-D-AL_Catalog.pdf -
VIDEO LINK
http://youtu.be/Vgth_9M5IRM?list=PL10BD55ADAF82DEDA
