Dixon® 1440812K
Dixon®

Dixon® 1440812K

loading

1440812K

Dixon® 1440812K Hose Barb, 3/4-16 x 1/2 in, 45 deg Female SAE Swivel UNF x Hose Barb, Brass, Domestic

  • Item#: 1440812K
  • Mfr#: 1440812K
    • All standard hose fittings are intended for use with hose clamps or crimped ferrules
    • 1/2 in tube OD
    • 1.34 in L stem
    • 0.84 in L nut
    • Warning: this product contains a chemical known to the state of California to cause birth defects or other reproductive harm
    • Do not use in connection with drinking water
    • Wash hands after handling
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Dixon® Hose Barb, Fitting/Connector Type: Adapter, 3/4-16 x 1/2 in Nominal, 45 deg Female SAE Swivel UNF x Hose Barb End Style, 7/8 in Hex, 4 Barb, 0.97 in Barb Length, Brass, Domestic

SPECIFICATIONS

Barb Length      :      0.97 in
Hex Size      :      7/8 in
Number of Barb      :      4
Fitting/Connector Type      :      Adapter
Nominal Size      :      3/4-16 x 1/2 in
End Style      :      45 deg Female SAE Swivel UNF x Hose Barb
Material      :      Brass
Domestic/Import      :      Domestic

DOCUMENTS

  • pdf
    Specification Sheet
    https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_Valve_Coupling_1020202C_Specification_Sheet.pdf
  • pdf
    Catalog
    https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Dixon_Valve_Coupling_144-0812_Catalog.pdf
  • video VIDEO LINK http://www.youtube.com/watch?v=BDMWIoXXsYk&list=PL10BD55ADAF82DEDA&feature=share&index=22
