VS-331
Browning® 767505 VS Series Medium Duty Straight Bore Ball Bearing Insert With Seal Flinger, 1.938 in Dia Bore, 3.937 in OD, 2.188 in W, 7889 lb Dynamic/5216 lb Static Load
- CP#:
- Item#: VS-331-P01
- Mfr#: VS-331
- Single setscrew locking
- Single lip contact seal
- Zone hardened inner race
- Lithium complex NLGI #2 grease with an EP additive
- Spherical outer diameter
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Browning® mounted ball bearings feature multiple housing styles, materials and configurations, an extended inner race insert bearing with ball riding nylon retainer. The insert features a rivet to prevent outer ring rotation and is available with setscrew, eccentric or BOA concentric locking collar. The contact seal with black oxide treated flinger provides a good balance between contaminant resistance, grease loss and friction.
Browning® Ball Bearing Insert, Medium Duty Straight Bore, Series: VS Series, 1.938 in Bore, 3.937 in OD, 2.188 in Width, Double Seal Closure, 7889 lb Dynamic/5216 lb Static Load, Steel Bearing, Plastic Cage, 2500 rpm Maximum, -20 to 200 deg F, Black Oxide Coated
SPECIFICATIONS
| Series | : | VS Series |
| Bearing Material | : | Steel |
| Closure Type | : | Double Seal |
| Finish | : | Black Oxide Coated |
| Load Capacity | : | 7889 lb Dynamic/5216 lb Static |
| Maximum Speed | : | 2500 rpm |
| Outside Diameter | : | 3.937 in |
| Inside Diameter | : | 1.938 in |
| Mounted | : | Yes |
| Width | : | 2.188 in |
