Browning®
Q3 2 7/16
Browning® 1079623 Type Q3 Split-Taper Bushing, 2-7/16 in Dia Bore, 2.609 in Dia Small End/2-7/8 in Dia Large End Dia Barrel, 4-1/8 in Dia Flange, 5 in OAL, Ductile Iron or Sintered Steel
- Item#: Q3 2 7/16BRO
- Mfr#: Q3 2 7/16
- Keyed to both shaft and hub, external key provides positive drive with no torque on the cap screws
- Highest torque carrying capacity
- Double split barrel assures true concentricity grips the shaft with positive clamp fit
- Solid flange and double split barrel, assures better concentricity to the shaft
- 3/4 in/ft taper on barrel, Self-locking taper provides the highest degree of mechanical locking product to product
- Key to key drive with keys on both the shaft and product to provide the strongest possible drive
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
External key provides positive drive with no torque on the cap screws. We offer high torque carrying capacity. Double split barrel improves true concentricity. The shaft is gripped with positive clamp fit.
Browning® Split-Taper Bushing, Type Q3, 2-7/16 in Bore, 2.609 in Dia Small End/2-7/8 in Dia Large End Barrel Diameter, 3-3/8 in Diameter Bolt Circle, 4-1/8 in Diameter Flange, 0.531 in Flange Thickness, 3 Bolt Holes, 3/8 x 1-1/4 in Screw, For Use With: Gearbelt® Multiple Groove Sheaves, 5 in Overall Length, Ductile Iron or Sintered Steel
SPECIFICATIONS
| Bolt Circle Diameter | : | 3-3/8 in |
| Flange Thickness | : | 0.531 in |
| Number of Bolt Holes | : | 3 |
| Screw Size | : | 3/8 x 1-1/4 in |
| Suitable For Use With | : | Gearbelt® Multiple Groove Sheaves |
| Type | : | Type Q3 |
| Bore Diameter | : | 2-7/16 in |
| Barrel Diameter | : | 2.609 in Dia Small End/2-7/8 in Dia Large End |
| Flange Diameter | : | 4-1/8 in |
| Overall Length | : | 5 in |
| Material | : | Ductile Iron or Sintered Steel |
