Browning® 1076397 Type P Q-D® Bushing, 6 in Dia Bore, 8-1/4 in Dia Barrel, 11-3/4 in Dia Flange, 9.39 in OAL, Cast Iron
- CP#:
- Item#: P 6BRO
- Mfr#: P 6
- Reverse mounting ability bushing system allows for mounting on either side of the product to allow for a more flush view of the product face
- 3/4 in/ft taper on barrel
- Self-locking taper provides the highest degree of mechanical locking product to product
- Conventional mounting
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Browning® Q-D? Bushing, Type P, 6 in Bore, 8-1/4 in Barrel Diameter, 10 in Diameter Bolt Circle, 11-3/4 in Diameter Flange, 1-3/4 in Flange Thickness, 4 Bolt Holes, 1-8 x 9-1/2 in Screw, 250000 in-lb Torque, For Use With: Gearbelt® Sheaves, Sprockets and Pulleys, 9.39 in Overall Length, 1-1/2 x 3/4 in Keyway, Cast Iron
SPECIFICATIONS
| Flange Thickness | : | 1-3/4 in |
| Keyway Size | : | 1-1/2 x 3/4 in |
| Bore Diameter | : | 6 in |
| Overall Length | : | 9.39 in |
| Material | : | Cast Iron |
| Type | : | Type P |
| Bolt Circle Diameter | : | 10 in |
| Number of Bolt Holes | : | 4 |
| Suitable For Use With | : | Gearbelt® Sheaves, Sprockets and Pulleys |
| Screw Size | : | 1-8 x 9-1/2 in |
| Barrel Diameter | : | 8-1/4 in |
| Flange Diameter | : | 11-3/4 in |
