D80R30
Browning® 1175041 Double Strand Type 12 Roller Chain Sprocket, 1-1/8 to 3-3/4 in Dia Bore, 10.114 in OD, 80 Chain, 30 Teeth, 1 in Pitch, Steel
- CP#:
- Item#: D80R30BRO
- Mfr#: D80R30
- This product has the Browning® exclusive twice the life guarantee
- Hardened teeth at no extra cost, drives sizes up to 30 teeth on 35 through 160 chain
- External key, higher torque capacity, aligns bolt holes
- Provides key to key drive
- Double split barrel, improved clamping
- Solid flange, true concentricity, easy installation
- Longer barrel, better support on the shaft
- For use with 1 in pitch ANSI chain
- Easy installation and removal
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Browning® offers a variety of bushing type sprockets available in single and double strands. Offerings include 35 to 160 pitch range. Bushed type bore ranges are available from 1/2 to 5 in. Hardened teeth are available up to 30 teeth.
Browning® Roller Chain Sprocket, Double Strand Type 12, 1-1/8 to 3-3/4 in Bore, 10.114 in OD, 80 Chain, 30 Teeth, 9.567 in Pitch Diameter, 5-3/8 in Diameter Hub, 3.1414 in Length Through Bore, Steel
SPECIFICATIONS
| Bushing Type | : | Split Taper |
| Bore Diameter | : | 1-1/8 to 3-3/4 in |
| Outside Diameter | : | 10.114 in |
| Chain Size | : | 80 |
| Number of Teeth | : | 30 |
| Pitch | : | 1 in |
| Material | : | Steel |
| Hub Diameter | : | 5-3/8 in |
| Length Through Bore | : | 3.1414 in |
| Pitch Diameter | : | 9.567 in |
| Type | : | Double Strand Type 12 |
