Browning® D60B11
Browning®

Browning® D60B11

loading
Browning®

D60B11

Browning® 1126085 Double Strand Minimum Bore Type B Roller Chain Sprocket With Hardened Teeth, 1 to 1-1/4 in Dia Bore, 3 in OD, 60 Chain, 11 Teeth, 3/4 in Pitch, Steel

  • Item#: D60B11-P01
  • Mfr#: D60B11
    • Larger hub diameter allows larger bore capacity
    • Maximum bore shown will accommodate standard keyways and setscrews over keyway
    • Slightly larger bores are possible with no keyway, shallow keyway or setscrew at angle to keyway
    • Hub projection on one side
    • High quality, high carbon steel
    • Lasts longer than sprockets made from low carbon steel
    • Large hub diameters, provides flexibility when reboring
    • For use with 3/4 in pitch ANSI chain
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Browning®Type B minimum bore sprockets are offered in single, double and triple strands. Offerings include 25 to 200 pitch range. Minimum bore sprockets are available in bore ranges from 1/4 to 8-3/8 in.

Browning® Roller Chain Sprocket, Double Strand Minimum Bore Type B, 1 to 1-1/4 in Bore, 3 in OD, 60 Chain, 11 Teeth, 2.662 in Pitch Diameter, 2-5/32 in Diameter Hub, 2-1/8 in Length Through Bore, Steel

SPECIFICATIONS

Bore Diameter      :      1 to 1-1/4 in
Outside Diameter      :      3 in
Chain Size      :      60
Number of Teeth      :      11
Material      :      Steel
Hub Diameter      :      2-5/32 in
Length Through Bore      :      2-1/8 in
Pitch Diameter      :      2.662 in
Type      :      Double Strand Minimum Bore Type B
