- Browning® B8MCS-80-36
B8MCS-80-36
Browning® 2765741 Type BF Solid Synchronous Flanged Sprocket, 22.225 to 82.55 mm, 202 mm OD, 203.708 mm Dia Pitch, 47.24 mm W Face
- CP#:
- Item#: B8MCS-80-36-P01
- Mfr#: B8MCS-80-36
- Positive drive, no slip
- Significantly quieter operation
- 98% efficient through a wide range of applications and speeds
- Ideal for mid-range torque applications
- Suited for applications over 500 rpm
- 80 teeth
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Browning® HPT Chain™ Synchronous Flanged Sprocket, Type BF Solid, 22.225 to 82.55 mm Bore, 202 mm OD, 203.708 mm Pitch Diameter, 8 mm Pitch, 47.24 mm Face Width, 213.0044 mm Diameter Flange, 146.05 mm Diameter Hub, 3.56 mm Hub Projection, 3020 Bushing, For Use With: 36 mm W Type 8M36 Belt
SPECIFICATIONS
| Bushing Type | : | 3020 |
| Pitch | : | 8 mm |
| Bore Diameter | : | 22.225 to 82.55 mm |
| Outside Diameter | : | 202 mm |
| Pitch Diameter | : | 203.708 mm |
| Face Width | : | 47.24 mm |
| Type | : | Type BF Solid |
| Hub Diameter | : | 146.05 mm |
| Flange Diameter | : | 213.0044 mm |
| Hub Projection | : | 3.56 mm |
| Suitable For Use With | : | 36 mm W Type 8M36 Belt |
