80R42
Browning® 1172030 Single Strand Split Taper Bushed Type 4 Roller Chain Sprocket, 1-1/8 in Dia Bore, 13.944 in OD, #80 Chain, 42 Teeth, Steel
- CP#:
- Item#: 80R42BRO
- Mfr#: 80R42
- This product has the Browning® exclusive twice the life guarantee
- Easy installation and removal
- Hardened teeth at no extra cost, drives sizes up to 30 teeth on 35 through 160 chain
- External key higher torque capacity, aligns bolt holes
- Provides key-to-key drive
- Double split barrel improved clamping
- Solid flange true concentricity
- Longer barrel better support on the shaft
- For use with 1 in pitch ANSI chain
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Browning® offers a variety of bushing type sprockets available in single and double strands. Offerings include 35 to 160 pitch range. Bushed type bore ranges are available from 1/2 to 5 in. Hardened teeth are available up to 30 teeth.
Browning® Roller Chain Sprocket, Single Strand Split Taper Bushed Type 4, 1-1/8 in Bore Dia, 13.944 in Outside Dia, #80 Chain, 42 Teeth, 13.381 in, 5-3/8 in Hub Dia, 3.1563 in Length Through Bore, Steel
SPECIFICATIONS
| Overall Length | : | 3.157 in |
| Bushing Type | : | Split Taper |
| Bore Diameter | : | 1-1/8 in |
| Outside Diameter | : | 13.944 in |
| Chain Size | : | #80 |
| Number of Teeth | : | 42 |
| Pitch | : | 1 in |
| Material | : | Steel |
| Type | : | Single Strand Split Taper Bushed Type 4 |
| Pitch Diameter | : | 13.381 in |
| Hub Diameter | : | 5-3/8 in |
| Length Through Bore | : | 3.1563 in |
