3333226
Browning® 3333226 Single Strand Roller Chain Sprocket With Hardened Teeth, 1/2 in Dia Bore, 2.652 in OD, #40 Chain, 15 Teeth, 1/2 in Pitch, Steel
- CP#:
- Item#: H40JA15-P01
- Mfr#: 3333226
- UPC: 662289242955
- This product has the Browning® exclusive twice the life guarantee
- Easy installation and removal
- Reverse mounting possible
- For use with 1/2 in pitch ANSI chain
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Browning® offers a variety of bushing type sprockets available in single and double strands. Offerings include 35 to 160 pitch range. Bushed type bore ranges are available from 1/2 to 5 in. Hardened teeth are available up to 30 teeth.
Browning® Roller Chain Sprocket, Single Strand, 1/2 in Bore Dia, 2.652 in Outside Dia, #40 Chain, 15 Teeth, 1/2 in Pitch, 2.405 in, 2.015 in Hub Dia, 0.89 in Length Through Bore, Type QD®-1 Bushing, Steel
SPECIFICATIONS
| Overall Length | : | 1.337 in |
| Bushing Type | : | Q-D |
| Bore Diameter | : | 1/2 in |
| Outside Diameter | : | 2.652 in |
| Chain Size | : | #40 |
| Number of Teeth | : | 15 |
| Pitch | : | 0.5 in |
| Material | : | Steel, Hardened Teeth |
| Type | : | Single Strand |
| Pitch Diameter | : | 2.405 in |
| Hub Diameter | : | 2.015 in |
| Length Through Bore | : | 0.89 in |
DOCUMENTS
-
Manual https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Browning_35JA20_Manual.pdf -
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Browning_40SH35_Specification_Sheet.pdf
