1172519
Browning® 1172519 Single Strand Roller Chain Sprocket, 3/4 in Dia Bore, 14.639 in OD, #100 Chain, 35 Teeth, 1-1/4 in Pitch, Steel
- CP#:
- Item#: 100Q35BRO
- Mfr#: 1172519
- UPC: 662289227488
- This product has the Browning® exclusive twice the life guarantee
- Easy installation and removal
- External key higher torque capacity, aligns bolt holes
- Provides key-to-key drive
- Double split barrel improved clamping
- Solid flange true concentricity
- Longer barrel better support on the shaft
- For use with 1-1/4 in pitch ANSI chain
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Browning® offers a variety of bushing type sprockets available in single and double strands. Offerings include 35 to 160 pitch range. Bushed type bore ranges are available from 1/2 to 5 in. Hardened teeth are available up to 30 teeth.
Browning® Roller Chain Sprocket, Single Strand, 3/4 in Bore Dia, 14.639 in Outside Dia, #100 Chain, 35 Teeth, 1-1/4 in Pitch, 13.945 in, 4-1/8 in Hub Dia, 2-1/2 in Length Through Bore, Type 4 Split Taper Bushing, Steel
SPECIFICATIONS
| Overall Length | : | 2.888 in |
| Bushing Type | : | Split Taper |
| Bore Diameter | : | 3/4 in |
| Outside Diameter | : | 14.639 in |
| Chain Size | : | #100 |
| Number of Teeth | : | 35 |
| Pitch | : | 1.25 in |
| Material | : | Steel |
| Type | : | Single Strand |
| Pitch Diameter | : | 13.945 in |
| Hub Diameter | : | 4-1/8 in |
| Length Through Bore | : | 2-1/2 in |
DOCUMENTS
-
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Browning_100Q32_Specification_Sheet.pdf -
Manual https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/Browning_35JA20_Manual.pdf
