MU1307UM
Bower® MU1307UM M Series Cylindrical Roller Bearing, 35 mm Dia Bore, 80 mm OD, 1 Row, 21 mm W, 90500 N Load
- CP#:
- Item#: MU1307UM
- Mfr#: MU1307UM
- The M series designated by the letter M satisfies most commercial applications
- Used where bearing must be assembled as a unit and where design has no provision to retain outer ring axially
- Will not accommodate thrust loads or locate shaft
- ISO class 0 tolerance rating
- CN radial clearance
- Round bore
- 79500 N dynamic/90500 N static
- Without oil hole
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Cylindrical roller bearings are manufactured by NTN Bower® in several series that differ in proportion, width, and load rating. Bore size for each series increases in multiples of five or more millimeters and for each bore size a selection of different narrow and wide series is available to meet the needs of most applications. External dimensions and tolerances conform to RBEC 1 metric bearing standards as defined in the American Bearing Manufacturers Association (ABMA) and American National Standards Institute (ANSI). NTN Bower® standard product lines include two basic series the M series for light and medium radial loads and the W series for heavy to extra heavy radial loads. Only complete bearing assemblies interchange between the Max-Pak and the M series bearings separable rings and roller assemblies do not.
Bower® Cylindrical Roller Bearing, Series: M Series, 35 mm Bore Dia, 80 mm Outside Dia, 1 Row, 21 mm W, Open Closure, 90500 N, Hardened Alloy Steel Bearing, -40 to 120 deg C
SPECIFICATIONS
| Series | : | M Series |
| Bearing Material | : | Hardened Alloy Steel |
| Load Capacity | : | 90500 N |
| Outside Diameter | : | 80 mm |
| Number of Rows | : | 1 |
| Width | : | 21 mm |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/421/Bower_M1013W_Catalog.pdf -
VIDEO LINK
https://youtu.be/4rXPAd9xD3w
