MA5219EL
Bower® MA5219EL M Series Cylindrical Roller Bearing, 95 mm Dia Bore, 170 mm OD, 1 Row, 55.562 mm W, 355000 N Load
- CP#:
- Item#: MA5219EL
- Mfr#: MA5219EL
- The M series designated by the letter M satisfies most commercial applications
- Permits axial float of shaft
- Accommodates contraction or expansion at one end of a shaft bearing at opposite end locates shaft
- ISO class 0 tolerance rating
- CN radial clearance
- Round bore
- 355000 N dynamic/53000 N static
- Without oil hole
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Cylindrical roller bearings are manufactured by NTN Bower® in several series that differ in proportion, width, and load rating. Bore size for each series increases in multiples of five or more millimeters and for each bore size a selection of different narrow and wide series is available to meet the needs of most applications. External dimensions and tolerances conform to RBEC 1 metric bearing standards as defined in the American Bearing Manufacturers Association (ABMA) and American National Standards Institute (ANSI). NTN Bower® standard product lines include two basic series the M series for light and medium radial loads and the W series for heavy to extra heavy radial loads. Only complete bearing assemblies interchange between the Max-Pak and the M series bearings separable rings and roller assemblies do not.
Bower® Cylindrical Roller Bearing, Series: M Series, 95 mm Bore Dia, 170 mm Outside Dia, 1 Row, 55.562 mm W, Open Closure, 355000 N, Hardened Alloy Steel Bearing, Composite Steel Cage, -40 to 120 deg C
SPECIFICATIONS
| Series | : | M Series |
| Bearing Material | : | Hardened Alloy Steel |
| Load Capacity | : | 355000 N |
| Outside Diameter | : | 170 mm |
| Number of Rows | : | 1 |
| Width | : | 55.562 mm |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/421/Bower_M1013W_Catalog.pdf -
VIDEO LINK
https://youtu.be/4rXPAd9xD3w
