M1212EAHL
Bower® M1212EAHL ULTAGE® M Series Type EA Cylindrical Roller Bearing, 72.39 mm Dia Bore, 110.056 mm OD, 1 Row, 22 mm W, 95500 N Load
- CP#:
- Item#: M1212EAHL
- Mfr#: M1212EAHL
- The M series designated by the letter M satisfies most commercial applications
- Oversized OD for heavy press fit in standard housing bore
- Up to 20% higher dynamic load rating nearly doubles bearing life
- Optimized internal geometry increases max speed by 20%
- Dimensionally interchangeable with conventional cylindrical roller bearings
- Improved bottom line due to less downtime and maintenance
- ISO class 0 tolerance rating
- CN radial clearance
- 78000 N dynamic/95500 N static
- Without oil hole
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
Cylindrical roller bearings are manufactured by NTN Bower® in several series that differ in proportion, width, and load rating. Bore size for each series increases in multiples of five or more millimeters and for each bore size a selection of different narrow and wide series is available to meet the needs of most applications. External dimensions and tolerances conform to RBEC 1 metric bearing standards as defined in the American Bearing Manufacturers Association (ABMA) and American National Standards Institute (ANSI). NTN Bower® standard product lines include two basic series the M series for light and medium radial loads and the W series for heavy to extra heavy radial loads. Only complete bearing assemblies interchange between the Max-Pak and the M series bearings separable rings and roller assemblies do not.
Bower® Cylindrical Roller Bearing, Type EA, Series: ULTAGE® M Series, 72.39 mm Bore Dia, 110.056 mm Outside Dia, 1 Row, 22 mm W, Open Closure, 95500 N, Hardened Alloy Steel Bearing, Composite Steel Cage, -40 to 120 deg C
SPECIFICATIONS
| Series | : | ULTAGE® M Series |
| Bearing Material | : | Hardened Alloy Steel |
| Load Capacity | : | 95500 N |
| Outside Diameter | : | 110.056 mm |
| Number of Rows | : | 1 |
| Width | : | 22 mm |
DOCUMENTS
-
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/421/Bower_M1013W_Catalog.pdf -
