OS200J03
ABB OS200J03 OS Series Fusible Open Disconnect Switch, 1000 VAC, 200 A, 150 hp, 1NC-1NO Contact, 3 Poles
- CP#:
- Item#: OS200J03
- Mfr#: OS200J03
- UPC: 662019161679
- Finger proof - dead front construction plus terminal shrouds reduce the risk of touching live parts, improving safety and reliability of the installation
- Switches can be used equally well with either top or bottom incoming power feed
- Modular construction
- The handle and shaft provide door interlock so that the door cannot be opened when the switch is in the on position
- Handles can be padlocked in the "OFF" position with up to three padlocks
- Welded contact protection
- Clear position indication
- Excellent track resistant material reduces the risk of flash over between phases in even the most severe circumstances
- Quick make, quick brake mechanism
- Fuses are totally isolated in the off position, reducing the risk of shock to authorized personnel
- Superior short circuit protection
- Front operated mode
- Class J fuse compatible
- 3-poles to the right of mechanism
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
ABB fusible switches are designed to meet customer requirements in terms of high interrupting capacity and long electrical life while occupying only little more panel space than the appropriate fuses. The basic construction provides flexibility and high performance in an extremely compact size. ABB's disconnects are a perfect choice to withstand the heat and humidity of the tropics, the extreme cold of the arctic and any rugged industrial environment you may have.
ABB Disconnect Switch, Fusible Open, Series: OS Series, 1000 VAC, 200 A, 150 hp, 3 Pole, 200 kA Short Circuit, 1NC-1NO Contact Form, Surface Mounting, Lug Terminal, 40 deg C, 218 mm H x 182 mm W x 132 mm D Dimensions
SPECIFICATIONS
| Mounting Type | : | Surface |
| Type | : | Fusible Open |
| Amperage Rating | : | 200 A |
| Horsepower | : | 150 hp |
| Number of Poles | : | 3 |
| Series | : | OS Series |
| Dimensions | : | 218 mm H x 182 mm W x 132 mm D |
| Short Circuit Current Rating | : | 200 kA |
| Terminal Type | : | Lug |
| Temperature Rating | : | 40 deg C |
| Voltage Rating | : | 1000 VAC |
| Contact Form | : | 1NC-1NO |
DOCUMENTS
-
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/1023/ABB_OS200J03_Specification_Sheet.pdf
