NL40E-80

ABB NL40E-80 NL Series DC Operated Control Relay, 10 A, 4NO Contact, 12 VDC V Coil

  • Item#: NL40E-80
  • Mfr#: NL40E-80
  • UPC: 662019188003
  • Contactor relays are used for switching auxiliary circuits and control circuits
  • DC operated with solid core magnet circuit
  • The polarity on the coil terminals (A1+ and A2-) must be respected
  • Contactors are fitted with low consumption DC coils and are suitable for a direct control by PLC outputs
  • 6 A at 24 VDC, 2.8 A at 48 VDC, 1 A at 72 VDC, 0.55 A at 125 VDC, 0.3 A at 250 VDC contact rating
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

ABB Control Relay, DC Operated, Series: NL Series, 10 A, 75 W Power, 25 to 400 Hz Frequency, 12 VDC Coil, 4NO Contact Form, 4 Pole, DIN Rail/Threaded Mounting, Screw Terminal, IP20 Enclosure, -40 to 55 deg C, 3.82 in L x 1.73 in W x 3.07 in H Dimensions

SPECIFICATIONS

Dimensions      :      3.82 in L x 1.73 in W x 3.07 in H
Enclosure Type      :      IP20
Frequency Rating      :      25 to 400 Hz
Mounting Type      :      DIN Rail/Threaded
Number of Poles      :      4
Power Rating      :      75 W
Series      :      NL Series
Temperature Rating      :      -40 to 55 deg C
Terminal Type      :      Screw
Type      :      DC Operated
Amperage Rating      :      10 A
Contact Form      :      4NO
Coil Voltage      :      12 Contact Form
