MEP4-0

ABB MEP4-0 EMPTY PLASTIC ENCLOSURE

  • Item#: MEP4-0
  • Mfr#: MEP4-0
  • UPC: 662019232386
  • 4-seat dark gray and light gray empty plastic enclosure
  • For mounting modular range pilot devices
  • 22 mm cutout diameter
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

Plastic enclosure

SPECIFICATIONS

Color      :      Dark Gray/Light Gray
Panel Size      :      22 mm
Temperature Rating      :      70 deg C
Length      :      0.061 mm
Width      :      0.221 m
Depth      :      0.075 mm
NEMA Rating      :      NEMA 1/3R/4/4X/12/13/IP66
Material      :      Plastic

DOCUMENTS

  • pdf
    Document
    https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_0b0c0e24972a5c24bf6b3f334f93283d02eef5dc4f4e4919d7e3a1662b6e8921.pdf
