AF40-30-11-13
ABB AF40-30-11-13 Non-Reversing Line Contactor, 100 to 250 VAC/VDC V Coil, 60 A, 3NO Contact, 3 Poles
- CP#:
- Item#: AF40-30-11-13
- Mfr#: AF40-30-11-13
- UPC: 888614152748
- Compact, space saving design
- Control circuit - AC or DC operated with electronic coil interface accepting a wide control voltage range (e.g. 100 to 250 VAC and VDC), only 4 control voltage ranges covering 24 to 500 V 50/60 Hz and 20 to 500 VDC
- Can manage large control voltage variations
- Reduced panel energy consumption
- Very distinct closing and opening
- Built-in surge suppression
- Add-on auxiliary contact blocks for front or side mounting and a wide range of accessories
- 70 A at 690 V, 60 A at 690 V, 50 A at 690 V rated operational current AC-1
- 40 A at 220/230/240 V, 40 A at 380/400 V, 40 A at 415 V, 40 A at 440 V, 35 A at 500 V, 25 A at 690 V rated operational current AC-3
- 15 hp at 220 to 240 VAC 3 ph, 30 hp at 440 to 480 VAC 3 ph, 40 hp at 550 to 600 VAC 3 ph, 3 hp at 120 VAC 1 ph, 10 hp at 200 to 208 VAC 3 ph, 7-1/2 hp at 240 VAC 1 ph
- 11 kW at 220/230/240 V, 18.5 kW at 380/400 V, 22 kW at 415 V, 22 kW at 440 V, 22 kW at 500 V, 22 kW at 690 V, 18.5 kW at 400 V
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
AF40 contactors are used for controlling power circuits up to 690 VAC and 220 VDC. They are mainly used for controlling 3 ph motors, non-inductive or slightly inductive loads. AF... contactors include an electronic coil interface accepting a wide control voltage Uc min. ... Uc max. Only four coils cover control voltages between 24 to 500 V 50/60 Hz or 20 to 500 VDC. AF contactors can manage large control voltage variations. One coil can be used for different control voltages used worldwide without any coil change. AF contactors have built-in surge protection and do not require additional surge suppressors. The AF... series 2-stack 3-pole contactors are of the block type design. - Main poles and auxiliary contact blocks: 3 main poles with side-mounted 1 NO + 1 NC auxiliary contact block, front-mounted add-on auxiliary contact blocks (mechanically-linked auxiliary contacts compliant with Annex L of IEC 60947-5-1 including the "Mechanically Linked" symbol on the contactor side. NC mirror contacts compliant with Annex F of IEC 60947-4-1) - Control circuit: AC or DC operated - Accessories: a wide range of accessories is available. Note: 2-stack contactors available in some countries: please consult your ABB representative. AF..-30-..-11 not suitable for a direct control by PLC-output.
ABB Line Contactor, Non-Reversing, Series: AF Series, 100 to 250 VAC/VDC Coil, 60 A Maximum Load Current, 15 hp, 30 hp, 40 hp, 3 hp, 10 hp, 7-1/2 hp Coil, 3 Pole, 11/18.5/22 kW Wattage, 3NO Contact Configuration, 1NO-1NC Auxiliary Contacts, 70 A at 690 V Contact, AF40 Size, Screw Terminal, IP10/IP20 Enclosure, 10000000 Cycles Operating Cycles, -40 to 70 deg C Operating, 2.17 in W x 4.37 in D x 4.7 in H Dimensions
SPECIFICATIONS
| Enclosure Type | : | IP10/IP20 |
| Type | : | Non-Reversing |
| Coil Voltage | : | 100 to 250 VAC/VDC |
| Contact Configuration | : | 3NO |
| Number of Poles | : | 3 |
| Operating Temperature | : | -40 to 70 deg C |
| Dimensions | : | 2.17 in W x 4.37 in D x 4.7 in H |
| Size | : | AF40 |
| Terminal Type | : | Screw |
| Wattage | : | 11/18.5/22 kW |
| Coil Power Rating | : | 15 hp, 30 hp, 40 hp, 3 hp, 10 hp, 7-1/2 hp |
| Contact Rating | : | 70 A at 690 V |
| Operating Cycles | : | 10000000 Cycles |
| Series | : | AF Series |
| Number of Auxiliary Contacts | : | 1NO-1NC |
| Maximum Load Current | : | 60 A |
