AF40-30-00-13
ABB AF40-30-00-13 AC/DC Operated IEC Contactor, 100 to 250 VAC/VDC V Coil, 42 A, 3NO Contact, 3 Poles
- CP#:
- Item#: AF40-30-00-13
- Mfr#: AF40-30-00-13
- UPC: 888614006836
- Control circuit: AC or DC operated with electronic coil interface accepting a wide control voltage range (e.g. 100 to 250 VAC and DC), only 4 control voltages ranges covering 24 to 500 V 50/60 Hz and 20 to 500 VDC
- Can manage large control voltage variations
- Reduced panel energy consumption
- Very distinct closing and opening
- Can withstand short voltage dips and voltage sags
- Built-in surge suppression
- 18.5 kW at 3-phase 400 V IEC, 30 hp at 440 to 480 VAC, 40 hp at 550 to 600 VAC
- 42 A at 220 to 240 VAC 3-phase UL/CSA
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
ABB IEC Contactor, AC/DC Operated, 100 to 250 VAC/VDC Coil, 42 A Maximum Load Current, 18.5 kW, 30 hp, 40 hp Coil, 3 Pole, 50/60 Hz Frequency, 3NO Contact Configuration, Double Connector Connection, Screw Terminal, IP10/IP20 Enclosure, 10000000 Cycles Operating Cycles, -60 to 80 deg C Operating, 125.5 mm H x 55 mm W x 111 mm D Dimensions
SPECIFICATIONS
| Connection Type | : | Double Connector |
| Frequency Rating | : | 50/60 Hz |
| Enclosure Type | : | IP10/IP20 |
| Type | : | AC/DC Operated |
| Coil Voltage | : | 100 to 250 VAC/VDC |
| Contact Configuration | : | 3NO |
| Number of Poles | : | 3 |
| Operating Temperature | : | -60 to 80 deg C |
| Dimensions | : | 125.5 mm H x 55 mm W x 111 mm D |
| Terminal Type | : | Screw |
| Coil Power Rating | : | 18.5 kW, 30 hp, 40 hp |
| Operating Cycles | : | 10000000 Cycles |
| Maximum Load Current | : | 42 A |
DOCUMENTS
-
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/1020/ABB_AF40-30-00-13_Specification_Sheet.pdf
