00118ES1RADD56N
WEG 00118ES1RADD56N Continuous-Duty AC Motor, Totally Enclosed Fan Cooled Enclosure, 1 hp, 115/230 VAC, 60 Hz, 1 ph Phase, D56N Frame, 1750 rpm Speed, Footless Mount
- CP#:
- Item#: 00118ES1RADD56N-P01
- Mfr#: 00118ES1RADD56N
- Double shielded ball bearings
- Two bolts mounting NEMA 'N' flange
- Extended shaft (NDE) with wrench flat for manual jogging of auger
- Centrifugal start switch protected against auger drive overspeed
- Manual reset thermal overload protection
- Min. Order Qty: 1
- Qty. Interval: 1
DESCRIPTION
WEG offers a complete line of TEFC Farm Duty motors providing high starting torque for the most demanding applications. Standard features such as v-rings provide versatility for indoor and outdoor applications. Overload protection available in all frames protects the motor from extreme overloads and offers maximum safety to operators.
WEG AC Motor, Continuous-Duty, Auger Drive Motors, Farm Duty Motors Application, 1 hp, 115/230 VAC, 14/7 A, 60 Hz Frequency, 1 ph ph, 1750 rpm Speed, Totally Enclosed Fan Cooled Enclosure, D56N Frame, 0.625 in Dia x 1.88 in L Shaft, CW/CCW Rotation, 1.15 Service Factor, Ball Bearing, 2.96 ft-lb Torque, Footless Mounting, -20 to 40 deg C, Insulation Class: Class B, Rolled Steel, 13.94 in L Dimensions
SPECIFICATIONS
| Horsepower | : | 1 hp |
| Torque Rating | : | 2.96 ft-lb |
| Material | : | Rolled Steel |
| Amperage Rating | : | 14/7 A |
| Type | : | Continuous-Duty |
| Shaft Size | : | 0.625 in Dia x 1.88 in L |
| Insulation Class | : | Class B |
| Bearing Type | : | Ball |
| Temperature Rating | : | -20 to 40 deg C |
| Service Factor | : | 1.15 |
| Dimensions | : | 13.94 in L |
| Rotation | : | CW/CCW |
| Application Type | : | Auger Drive Motors, Farm Duty Motors |
| Phase | : | 1 |
| Frame | : | D56N |
| Speed | : | 1750 rpm |
| Mounting Type | : | Footless |
| Enclosure Type | : | Totally Enclosed Fan Cooled |
DOCUMENTS
-
Engineering Drawing https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/469/WEG_00118ES1RADD56N_Full_Engineering_Drawing.pdf -
Specification Sheet https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/469/WEG_00118ES1RADD56N_Specification_Sheet.pdf -
Catalog https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/553/WEG_00336AS1RAF145TZ_S_Catalog.pdf -
Warranty https://www.purvisindustries.com//ASSETS/DOCUMENTS/ITEMS/EN/https://econtent.adhq.com/dam/Original/607/WEG_3336OT1BW56_S_Warranty.pdf
