51112

NACHI 51112 51100 Thrust Ball Bearing, 60 mm Dia Bore, 85 mm OD, 17 mm W, 41500 N Dynamic/113000 N Static Load

  • Item#: 51112
  • Mfr#: 51112
  • Thrust ball bearings are designed to handle axial loads only
  • Thrust ball bearings consist of ball, retainer, both shaft and housing washers which contain grooves for the balls and can be subject to axial load only
  • The bearings with spherical housing washer can prevent static misalignment
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading

DESCRIPTION

NACHI Thrust Ball Bearing, Series: 51100, 60 mm Bore, 85 mm OD, 17 mm Width, Flat Back Face, Single Thrust Direction, 41500 N Dynamic/113000 N Static Load, 2600 rpm Grease/3900 rpm Oil Maximum

SPECIFICATIONS

Face Type      :      Flat Back
Maximum Speed      :      2600 rpm Grease/3900 rpm Oil
Series      :      51100
Thrust Direction      :      Single
Bore Diameter      :      60 mm
Outside Diameter      :      85 mm
Width      :      17 mm
Load Capacity      :      41500 N Dynamic/113000 N Static

DOCUMENTS

  • pdf
    Specification Sheet
